Highly precise four-and-a-half-digit multimeter

Highly precise four-and-a-half-digit multimeter

• Universal measuring equipment that can measure AC/DC voltage, AC/DC current, temperature, resistance, and frequency.

  The Aneng AN870 multimeter is also equipped with many additional features, such as LED tester, true RMS, hold function, buzzer, and high-definition screen backlight.

  The maximum indicated value on the Aneng AN870 instrument display screen is 19999, which allows it to measure DC voltage with a minimum resolution of 1 µ V.

  This device allows for manual or automatic changes to the measurement range.

  Due to its ability to quickly and accurately measure various electrical parameters and equipped with many useful functions, this universal multimeter can be used in many fields, such as electronics, electrical engineering, diagnosis, maintenance, and so on.

  The PRO version includes additional elements from the suite.

• Multiple measurement functions

  The universal multimeter Aneng AN870 is equipped with many functions, making it an extremely useful device in diagnostic work.

  Features of Anneng AN870:

  DC voltage measurement (DC)

  AC voltage measurement (AC)

  Measurement of Direct Current (DC)

  AC current measurement (AC)

  temperature measurement

  Resistance measurement

  Measurement of capacitance of capacitors

  frequency measurement

  Continuity test (buzzer)

  Diode testing

  NCV testing

  True effective value

  Identification of Line 0

• Other features of the product:

  Automatically or manually changing the measurement range

  Large, easy to read LCD display screen

  Maximum reading 19999

  Screen backlight

  Maintain function (stop the indication on the instrument screen)

  Record of maximum and minimum values during the measurement process

  Automatically shut down after 15 minutes of inactivity (can be turned off)

  Relative measurement - zero the instrument

  Mileage filling rate measurement

  Measure temperature from the end of the thermocouple or measure ambient temperature using an internal semiconductor diode (after disconnecting the thermocouple)

  Can set temperature measurement in Celsius or Fahrenheit

• power supply

  The AN870 universal measuring device is powered by two 1.5V AA batteries.

  liquid crystal display

  This instrument is equipped with a backlight high-definition LCD screen, which displays the measurement results.

  Compact size

  This multimeter has a small volume and is very convenient to use, so you can carry it with you anytime.

• DC voltage measurement: 19999V/19999V/199,99V/1000,0V/1999mV/199,99mV,+(0,05%+3)

  AC voltage measurement: 19999V/19999V/199,99V/750,0V/1999mV/199,99mV,+(0,3%+3)

  AC current measurement: 19999A/19999A/19999mA/199,99A/199,99 µ A/1999,9 µ A, ± (0,8%+3)

  DC current measurement: 19999A/19999A/19999mA/199,99A/199,99 µ A/1999,9 µ A, ± (0,5%+3)

  Temperature measurement: -20~1000 ℃ (-4~1832 ℉)

  Resistance measurement: 199,99 Ω/19999k Ω/19999k Ω/1999.99 Ω/1999.99 M Ω/1999.99 M Ω/1999.99 M Ω

  Capacity measurement: 9.999nF/9.999nF/9.999nF/9.999uF/9.999uF/9.999uF/9.999MF

  Frequency measurement: 99,99Hz/999,9Hz/999kHz/99,99kHz/999,9kHz/999MHz

  Working mode: automatic or manual

  Maximum indication: 19999

  Display: LCD

  Power supply: 2 AA 1.5V batteries

  Security level:

  Material: ABS

  Dimensions: 168 x 88 x 44 (millimeters)

  Weight: 323 grams

• Packaging content:

  Anneng AN87 Multimeter

  Accessory set (as shown in the picture)

  case

  Storage bag * 1
