Kadimendium Electric Scooter Controller Sinusoid Solution Remote Control Set with Low Voltage Alarm for Scooters and Balance Scooters

1. [ENHANCED CONTROL] Gain better control over your scooter with this dual drive hub motor control panel. 2. [REMOTE MONITORING] Stay informed about your scooter's power levels with the remote control feature. 3. [RELIABLE PROTECTIONS] Provides low voltage alarm, undervoltage, and power failure protection for safety. 4. [STURDY CONSTRUCTION] Durable ABS material ensures long-term reliability and performance. 5. [WIDE COMPATIBILITY] Suitable for various types of scooters, unicycles, and balance scooters for versatile use. Spec: Item type: Scooter Controller Set Material: Electronic components + ABS Color: As picture shown Weight: Approx. 280g Drive mode: dual system drive Induction method: for hall Controller type and performance Controller Types Operating voltage range Total power of controller Control electric quantity T2 wireless dual drive DC voltage 36V/24V 1300W 2 Control motor type and performance Motor type Maximum power of motor Motor speed Can not connect the motor for hall DC Brushless Motor Within 650W Within 8000 rpm can not connect Maximum power: 430W (36V) Speed: 4200 RPM Maximum speed: 35KM/H Power connector: XT60 male plug Carrying weight: ≤120KG Long-distance distance: up to 20 meters Protection: overvoltage, undervoltage, overheating, stall, CW/CCW, adjustable speed Current: 12A Voltage: 36V, 10S Remote control built-in lithium battery The capacity of the remote control: 400MAH Total length of remote control: Approx. 12cm/4.7in Remote control length: Approx. 6cm/2.4in Circuit board size: Approx. 10.5x8cm/4.1x3.1in Application areas: scooters, unicycles, balance scooters Note: Different voltage, alarm voltage, protection voltage are different Suitable for hub motor model airplane motor 5055 5065 6354 6364 6374 6384 How to choose the right controller: 1. Confirm the voltage of your battery 6 series battery is 25.2V, 7 series battery is 29.4V, 10 series battery is 36V 2. Confirm the motor type External motor, chain, belt drive, use belt controller Hub motor, motor integrated wheel, please select the controller with the word “hub” 3. Confirm single-drive or four-wheel drive A controller drives a motor is a single drive One controller drives two motors is dual drive One controller drives four motors is four-wheel drive : Do not connect motor cables in parallel to allow single drive to drive two motors Electric four-wheel scooter control system: Adopting the sinusoid scheme, the performance is more stable than the ESC, and it is not easy to burn out Description of matching signal between remote control and main controller: 1. Connect the main controller to the power supply. 2. Turn on the power, wait for two seconds and then press and hold the key for about 6 seconds, let go when the switch indicator flashes. 3. Turn on the remote control switch and use a small screwdriver to press the button in the small hole in the lower left corner of the remote control. 4. Turn off the remote control and turn it on for two seconds. Wait for the remote control signal light and the switch signal light to flash at the same time to indicate that the configuration is successful. About the motor for hall wire connection description: At present, the normal version and standard version of the controller need to provide conventional connection methods for the phase sequence. The brushless motor is controlled by 3 phases and 6 ways. 3 for hall states correspond to 3 motor wires and 6 output states. There are 36 connections for different combinations. , Among them, there are 6 kinds of connections that can make the motor run normally, and 3 of these 6 kinds of connections are forward rotation and the other 3 are reverse rotation. 1. First, let the motor rotate normally, usually the for hall plug is directly plugged in to adjust the motor line. 1. Motor wire blue to controller blue, motor wire green to controller green, motor wire yellow to controller yellow. 2. The blue of the motor wire is blue to the controller, the green of the motor wire is yellow to the controller, and the yellow of the motor wire is green to the controller. 3. Motor wire yellow to controller yellow, motor wire blue to controller green, motor wire green to controller blue. 4. Motor wire green to controller green, motor wire blue to controller yellow, motor wire yellow to controller blue. 5. Motor wire blue to controller yellow, motor wire yellow to controller green, motor wire green to controller blue. 6. Motor wire yellow to controller blue, motor wire blue to controller green, motor wire green to controller yellow. Generally, the controller is placed on the top and the motor is placed on the bottom 1.) Color vs. Color 2.) Blue to blue, the other 2 colors are reversed 3.)

• [ENHANCED CONTROL] Gain better control over your scooter with this dual drive hub motor control panel.
• [REMOTE MONITORING] Stay informed about your scooter's power levels with the remote control feature.
• [RELIABLE PROTECTIONS] Provides low voltage alarm, undervoltage, and power failure protection for safety.
• [STURDY CONSTRUCTION] Durable ABS material ensures long-term reliability and performance.
• [WIDE COMPATIBILITY] Suitable for various types of scooters, unicycles, and balance scooters for versatile use.
