ST209 6000 Counts True RMS Digital Professional Multimeter Clamp DC/AC Current Clamp Tester Meters Voltmeter Auto Range(Black)

Multimeters & AnalyzersST209 6000 Counts True RMS Digital Multimeter Clamp MeterA.Feature:1-1.Display: liquid crystal display ();1-2. Maximum display: 5999 (35/6) bit automatic polarity display;1-3. Measurement method: double integral A/D conversion;1-4. Sampling rate: about 3 times per second;1-5. Overrange display: The highest position shows"OL";1-6.Low voltage display:"Low voltage symbol"symbol appears;<;80%;1-8.Power: AAA 1.5V battery(notincluida);B.Function: Voltage DCAYesAC Voltage ACVYes Current DCAYesAC Current ACAYesResistorYesFrequencyYesSuqare Wave OutputYesNCVYesOn-off TestYesFull Unit SymbolYesBacklight Manual/Auto OffYesTrue RMS MeasureYesTemperatureYesFlashlight LightingYesDiodeYesCapacitorYesFunctionRangeAccuracyResolution Voltage6V/60V/600V+-(0.8%+10)0.001V/0.01V/0.1V Voltage1000V+-(0.5%+3)1VAC Voltage6V/60V/600V+-(0.8%+3)0.001V/0.01V/0.1VAC Voltage750V+-(1.2%+10)1V Current60A/600A+-(2.5%+30)0.01A/0.1AAC Current60A/600A+-(2.5%+30)0.01A/0.1AResistance600+-(0.8%+5)0.16k/60k/600k/6M+-(0.8%+3)1/10/100/1k40M+-(2.5%+3)10kCapacitance60nF/600nF/6uF/60uF/600uF+-(3.5%+20)10pF/100pF/1nF/10nF/100nF6mF/30mF+-(5%+3)1uF/10uFFrequency10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz+-(0.1%+3)0.01Hz/0.1Hz/1Hz/10Hz/100Hz/1kHz/10kHzTemperature(-20~1000)As the Instructions1(0~1832)As the Instructions1C.Package:1* ST209 Clamp meter1* test pen,1* temperature probe1* storage bag1* instruction manualNOTE:This series of instruments is designed in accordance with IEC1010 (Safety Standards promulgated by the International Electrotechnical Commission), please read the safety precautions before use.1. When measuring voltage, please do not input the limit voltage exceeding the effective value of 1000V or AC 750V;2.The voltage below 2.36V is a safe voltage. When measuring higher than 36V and 25V AC voltage, check whether the test leads are in reliable contact, are connected correctly, and are well insulated to avoid electric shock;3. When changing functions and ranges, the test leads should leave the test point..==========Weight : about 330gDimensions : 170*65*30 mmOperating Temperature : (0-40) temperatureMeasuring Inductance Range : 10Hz-100Hz-1kHz-10kHz-100kHz-1MHz-10MHz +-(0.1%+3)Measuring Capacitance Range : 60nF-600nF-6uF-60uF-600uF-6mF-30mF +-(3.5%+20)Measuring Resistance Range : 600-6k-60k-600k-6M-40M +-(0.8%+3)Measuring Voltage Range : 6V-60V-600V-750V +-(0.8%+3)Measuring Current Range : 60A/600A +-(2.5%+30)Display Type : Digital OnlyModel Number : ST209 Clamp MeterDIY Supplies : ELECTRICALModel : ST209
